From the blank to the sensorQUALITY FROM ETH

In addition to a large standard range of rotating or static torque transducers, we also manufacture individual sensors according to customer requirements.
We value a high percentage of our own production of mechanical and electronic components.

Measuring Technologyproducts at a glance Downloadswhat you need

Measuring Technology

Torquesensor DRVL

for speed and angle measurement

27 measuring ranges up to 20.000 Nm

Voltage and frequency output
Advanced electromagnetic compatibility (EMC)
adjustable output level for speed- and angle signal (5 - 24 V)
larger speed range for speed- and angle measurements
optional 0,05% linearity error
Option "Mounting base"
Option "Mounting adapter"

Torquesensor DRBK

All-purpose, also available with display

11 measuring ranges from 0,5 Nm up to 1000 Nm

Low-Cost Torque transducer
Current output and voltage output
Very short
Measurement accuracy: ≤ 0.5% of full scale
Contactless transfer of measurement signal
Proven strain gage technology
Integrated signal amplifier
Single power supply
wide range of applications
Optional speed measurement

2-range-sensor DRDL

Torque sensor with 2 measuring ranges

16 Sizes from ±0 - 0,5 Nm up to 5000 Nm

two ranges synchronously without change-over
integral signal amplifier
low moment of intertia
single supply voltage
wide range of applications
contactless output signals
no maintance
various options available

GMV2

Multipurpose Torque Meter

Tool Testing
Production Supervising
Documentation conforming to DIN EN ISO 9001
Quality Assurance
Test Bench Evaluation

ValueMaster base

Measuring module with network connection

Measurement of torque, speed, angle, pressure, force and stroke
Connection of 2 sensors
Control I/O interface with signal output e.g. for SPC
Analysis of values on a PC using included software network connection with ethernet

ValueView-D-01

Supply and display device for active torque sensors

with display for torque, speed and pulse lengthening

24 bit resolution
up to 50 measurements per second
permanent min/max-display
tara-function
sensorfeeding
peak value measurement

DPFR-036

Friction measurement on gear with curve tracing

5 Nm respectively 30 U/min

Constant test speed independent of load
Selectable direction of rotation and speed
Eliminated lateral forces
Acquisition of torque and angle of rotation
Option OK and NOK signal lights

DPFR-027

Friction measurement on gear with curve tracing

10 Nm respectively 100 U/min

Constant load-independent test speed
Selectable direction of rotation and speed
Eliminated lateral forces
Acquisition of torque and angle of rotation
Reproducible test process

DPFR-002

Damper testing in a temperature cabinet

Testing equipment for quality control

Testing of material properties at different temperatures

Cyclic loading of the test object with torque in the temperature cabinet
freely programmable load sequence
Documentation of rotation angle and temperature

show all products
